Hot sale! Dongfeng D9 180hp diesel Euro 4 10cbm asphalt spreading tanker truck, 8tons bitumen distributing vehicle

    Buy cheap Hot sale! Dongfeng D9 180hp diesel Euro 4 10cbm asphalt spreading tanker truck, 8tons bitumen distributing vehicle from wholesalers

    Buy cheap Hot sale! Dongfeng D9 180hp diesel Euro 4 10cbm asphalt spreading tanker truck, 8tons bitumen distributing vehicle from wholesalers
    • Buy cheap Hot sale! Dongfeng D9 180hp diesel Euro 4 10cbm asphalt spreading tanker truck, 8tons bitumen distributing vehicle from wholesalers
    • Buy cheap Hot sale! Dongfeng D9 180hp diesel Euro 4 10cbm asphalt spreading tanker truck, 8tons bitumen distributing vehicle from wholesalers
    • Buy cheap Hot sale! Dongfeng D9 180hp diesel Euro 4 10cbm asphalt spreading tanker truck, 8tons bitumen distributing vehicle from wholesalers

    Hot sale! Dongfeng D9 180hp diesel Euro 4 10cbm asphalt spreading tanker truck, 8tons bitumen distributing vehicle

    Ask Lasest Price
    Brand Name : CLW
    Certification : CCC, ISO 9001
    Price : negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 20units/month
    Delivery Time : 20 days
    • Product Details
    • Company Profile

    Hot sale! Dongfeng D9 180hp diesel Euro 4 10cbm asphalt spreading tanker truck, 8tons bitumen distributing vehicle


    Hot sale! Dongfeng D9 180hp diesel Euro 4 10cbm asphalt spreading tanker truck for sale, 8tons bitumen distributing vehicle for sale


    Dongfeng D9 180hp diesel Euro 4 10cbm bitumen distributing tanker truck, adopts dongfeng D9 one row and a half luxurious driver cab, 4500mm wheelbase, ISD180-43 Cummins 180hp Euro Ⅳ diesel engine, 9,00R20 rail tires, 4.5t front axle/10t rear axle, 8 speed manual gearbox, etc.


    The devices of dongfeng D9 10cbm asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. is as below.

    1, the asphalt pump adopts high quality QGB950 (high viscosity asphalt pump, 950L/min).

    2, hydraulic system: Proportional valve (Taiwan EFBG-03-160-HF); Automatic reversing valve and overflow valve; radiator adopts Risheng brand; the model of hydraulic motor for asphalt pump: 05-110-BD31; hydraulic pump model: CBQ550-L or Power take off after engine GPC4-50R.

    3, control way: Intelligent touch screen computer control at the driver cab; control system: (Siemens, Germany), 36 sets intelligent asphalt spraying nozzles (one controls one).

    4, Heating method: Burner (Italy imported Riello brand burner model G20) + Automatic heating of heat transfer oil

    5, gasoline generator unit: 6KW

    6, spreading amount: 0.25-3.5L/㎡;

    7, asphalt distributing width: 4.5m, 48 sets spraying nozzles for 6m spreading width is selective (10000RMB additional).

    8, Distributing medium: emulsified asphalt, hot asphalt, SBS hot asphalt, etc.


    More pictures of dongfeng D9 10cbm asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.

    If you're interested in our asphal tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995

    Website: www.trucksinchina.com

    Main technical parameters of dongfeng D9 10cbm asphalt tanker spreading vehicle manufactured by Chengli Special Automobile Co., Ltd. is as below.

    Main technical parameters
    Product nameCLW5180GLQ6 asphalt spreading vehicle for sale
    Total mass(Kg)18000Tanker volume(m3)10.0
    Rated mass(Kg)8690,8625Overall dimension(L*W*H)(mm)8160×2500×3060
    Curb mass(Kg)9180Driver cab seated person2,3
    Approach/departure angle(°)19/15Front/rear suspension(mm)1260/2400
    Axle no.2wheelbase(mm)4500
    Axle load(Kg)6500/11500Max speed(Km/h)105
    Chassis main technical parameters
    Chassis modelEQ1185LJ9CDEManufacturerDongfeng company
    Approach/departure angle(°)19/13,19/17Tire specification10.00R20 18PR,
    Steel spring8/10+7,Front tread(mm)1933,
    Fuel typeDieselRear tread(mm)1865
    Emission standardEuro Ⅲ
    Engine modelManufacturerDisplacement (ml)Power(Kw)
    ISD180-43Cummins4500132

    The asphalt tank distributing vehicle is a kind intelligent automated high-tech special vehicle for distributing different kinds of asphalts such as emulsified asphalt, diluted asphalt, hot asphalt, High viscosity modified asphalt, etc. It is used for distributing the permeable oil waterproof layer on the bottom of asphalt pavement of high grade highways. The asphalt distributing vehicle is made up of truck chassis, asphalt tank body, asphalt pump delivering and spraying system, thermal oil heating system, hydraulic system, combustion system, control system, Pneumatic system, operation platform, etc.


    The bitumen distribution truck for sale are consisted with truck chassis, insulated asphalt tank, heater, hydraulic system, conducting oil pipeline, asphalt pump, spray nozzle, etc. The tank volume is from 3m3 to 18m3. The spray nozzle quantity is from 30 to 48 nos.


    The liquid bitumen sprayer truck is mainly used to transport asphalt and distribut it for sealing the road.


    Our asphalt distributor dopt advanced technology and foreign imported parts. It has more advantages than other asphalt suppliers.


    Our asphalt sparyer truck for sale adopt special chassis and Italy imported burner. It has many advantages.

    Quality Hot sale! Dongfeng D9 180hp diesel Euro 4 10cbm asphalt spreading tanker truck, 8tons bitumen distributing vehicle for sale
