customized SHACMAN brand XUANDE X6 4*2 LHD 180hp 6.3tons telescopiccrane boom mounted on truck for sale, HOT SALE!6.3TONS cargo truck with crane
CLW truck mounted crane is one of our main mature products which is
also named hydraulic truck crane, mobile crane, truck mounted
crane, lorry-mounted crane, lorry crane, truck with loading crane,
truck cargo crane and so on. It is widely used in various loading
and unloading, installation and lifting, especially in the field of
outdoor lifting, salvage operation and other narrow places such as
station, port, warehouse and construction site.
Product Notes of CLW brand truck mounted crane manufactured by
Chengli Special Automobile Co., Ltd. as below.
· Optional: from 2 ton to 200 ton lifting capacity crane truck
· Optional: straight arm and floding arm truck crane with or without remote
control
· Optional: different famous crane brand: HIAB, Shimei, Zoomlion, Sany, Chengli
balong, etc.
· Optional: different famous chassis brand: Dongfeng, FAW, Foton, Sinotruk,
Syter, Shaanxi, T-king, Dayun, Yuejin, JMC, JAC, etc.
· Factory direct sale, low price and good quality.
If you're interested in truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
Customized SHACMAN Brand xuande 4*2 LHD YUCHAI 180hp Euro 5 diesel cargo truck mounted with 6.3tons-8tons telescopic crane boom, adopts SHACMAN XUANDE X6 luxurious driver cab, 5200mm wheelbase, YC6JA180-50 yuchai 180hp diesel Euro 5 engine, fastgear 8 speed gearbox, 5tons front axle/10tons strengthen rear axle, 10.00R20 rail tyres, etc.
The cargo body dimension of SHACMAN XUANDE X6 4*2 LHD truck with crane is 5700*2400*550(mm);client choose to install China made CLW brand high quality 6.3tons/8tons telescopic/knuckle crane boom, etc.



The specification of SHACMAN Brand xuande 4*2 LHD YUCHAI 180hp Euro 5 diesel cargo truck mounted with 6.3tons-8tons telescopic crane boom as below
| Product name | SHACMAN Brand xuande 4*2 LHD YUCHAI 180hp Euro 5 diesel cargo truck mounted with 6.3tons-8tons telescopic crane boom | |
| Chassis type | SX1181GP5 | |
| Parameters | Overall dimension length/width/height (mm) | 8730,9000×2500,2550×3650,3850 |
| Cargo body dimension (L*W*H)(mm) | 5700*2400*550(mm) | |
| GVW(kg) | 18000(Kg) | |
| Kerb Mass(kg) | 11380 (Kg) | |
| Rated mass(kg) | 6425 (Kg) | |
| Approach angle/ Departure angle(mm) | 23/15 (°) | |
| Front suspension/rear suspension(mm) | 1450/2080 | |
| Fuel Type | diesel | |
| Max Speed | 95 | |
| Engine | Type | YC6JA180-50 |
| Displacement/Power(kw) | 6870ml/132KW/180hp | |
| Manufacturer | YUCHAI | |
| Chassis | Drive Type | 8*4 |
| Wheelbase(mm) | 5200 | |
| Tread(front/rear) | 1970/1860 (mm) | |
| Transmission | Fastgear 8 speed manual gearbox | |
| Braking system | Air braking | |
| Cab | SHACMAN XUANDE X6 luxurious driver cab | |
| Number of spring axle(front/rear) | 8/10+3 | |
| Tire Type | 10.00R20 | |
| Upper part(cargo van and crane boom) main parameters | ||
| Upper body | Cargo body dimension | 5700*2400*550(mm) |
| Material | Carbon steel | |
| Side sheet thickness | 2mm thickness | |
| Bottom sheet thickness | 2mm thickness | |
| Painting | Upon request | |
| Crane boom main parameters | ||
| Crane boom | Choose to install CLW brand 6.3T 3/4 sections telescopic crane boom | |
| Lifting height | 10.6m/13m | |
| Working radius | 8.6m/11m | |
| The color of the whole truck is upon request. | ||
|
