HOT SALE!new good price FOTON 4*2 LHD 16T mobile crane truck,Factory sale price 16T truck crane for sale

    Buy cheap HOT SALE!new good price FOTON 4*2 LHD 16T mobile crane truck,Factory sale price 16T truck crane for sale from wholesalers

    Buy cheap HOT SALE!new good price FOTON 4*2 LHD 16T mobile crane truck,Factory sale price 16T truck crane for sale from wholesalers
    • Buy cheap HOT SALE!new good price FOTON 4*2 LHD 16T mobile crane truck,Factory sale price 16T truck crane for sale from wholesalers
    • Buy cheap HOT SALE!new good price FOTON 4*2 LHD 16T mobile crane truck,Factory sale price 16T truck crane for sale from wholesalers
    • Buy cheap HOT SALE!new good price FOTON 4*2 LHD 16T mobile crane truck,Factory sale price 16T truck crane for sale from wholesalers

    HOT SALE!new good price FOTON 4*2 LHD 16T mobile crane truck,Factory sale price 16T truck crane for sale

    Ask Lasest Price
    Brand Name : CLW
    Certification : CCC
    Price : negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 20 units/month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    HOT SALE!new good price FOTON 4*2 LHD 16T mobile crane truck,Factory sale price 16T truck crane for sale


    HOT SALE!new good price FOTON 4*2 LHD 16T mobile crane truck,Factory sale price 16T truck crane for sale


    Mobile crane is also called truck crane, a kind of crane mounted on general truck chassis or special purpose truck chassis. The driving cabin and lifting operation cab are setted separately. The advantage of this kind of mobile truck crane is flexibility and moving quickly; while the weakness is work must be outrigger, cannot load driving and at the same time cannot work on the a soft or muddy field. And this kind of mobile truck crane is widely used for Engineering Constructions, such as Roads, bridges, buildings, emergency services, etc. The general engineering team, the construction industry and the electric power installment department, all needs the automobile crane.


    the technical advantages of CLW brand truck crane as below.
    1. Customized cab of truck crane
    2. Differentiated design, wide use scenarios
    3. Multi-task power platform is selected, and the application area is wide
    4. Single-board arm head, compact arm circumference, stilt-type counterweight box, work more convenient
    5. The intelligent lifting operation room can effectively reduce the driving height and improve the passing rate and stability of the whole machine.


    If you're interested in our crane truck, please send email to truck0011@163.com; or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995

    Website: www.trucksinchina.com


    Overall dimension(L*W*H): 10800*2370*3420
    crane boom: 9m 5 sections veneer U type boom
    full crane boom length: 39.5m
    engine model: weichai 190hp
    gearbox: fastgear
    wheelbase: 4500mm

    Tire specification: 1000R20 rail tires
    Main/auxiliary hoist: 16T/16T


    More pictures of FOTON 16T mobile crane truck manufactured by Chengli Special Automobile Co., Ltd. is as below.


    Main technical parameters of FOTON 4*2 LHD 16T mobile crane truck is as below.

    Foton 12T mobile crane truck for sale
    Total mass18000KGSMax lifting mass(kg)16000
    Engine model

    WP4.1NQ190E61

    Weichai 190hp

    Main/auxiliary hoist19T/19T
    Displacement/ power (ml/kw)4088/140Crane boom9m 5 sections veneer U type boom
    GearboxfastgearFull crane boom length (m)39.5
    Overall dimension(L*W*H)(mm)10800*2370*3420Big boom dimension(mm)600*500
    Wheelbase4500mmBack displacement topStandard
    Tires pec900R20 rail tiresSlewing bearingExternal gear
    Front/rear axle(kgs)6000/12000Slewing mechanism360°Arbitrary rotation
    Outrigger Longitudinal/transverse span(mm)5100/7100Beamnew torque-fighting van beam
    Steering typeHydraulic steeringPower pumpTriple-pump
    BrakingAir cut brakingOperation roomAdvanced operation room

    Others: 18.5T without payload, Fabricated process, double outriggers, extended boom of 15m length with the loading capacity of 16T, Truck-mounted oil circuit,


    Chosen part: 17KW electronic motor, computer, weighing apparatus, camera, rotating basket, air conditioning, level

    Main technical parameters of FOTON 16T mobile crane truck manufactured by Chengli Special Automobile Co., Ltd. as below.

    Main technical parameters
    Product nameBJ5184JQZHPFG-01 FOTON 16T mobile crane truck for sale
    Total mass(Kg)18000Overall dimension(L*W*H)10800*2370*3420
    Curb mass(Kg)17805Driver cab seated person3
    Approach/departure angle(°)17/10Front/rear suspension(mm)1260/2860
    Axle load2wheelbase(mm)4500
    Axle load(Kg)6000/12000Max speed(Km/h)85
    Chassis main parameters
    Truck chassisBJ1184VKPFG-01ManufacturerFOTON
    Approach/departure angle (°)21/26Tire specification10.00R20 18PR*6
    Steel spring10/12+9Front tread(mm)1755
    Fuel typeDieselRear tread(mm)1740,1724
    Emission standardEuro Ⅵ
    Engine modelManufacturerdisplacement(ml)power(Kw)
    WP4.1NQ190E61Weichai4088140
